Product Name (Chinese): Q7 Pro Max Electric Scooter
Scooter Model: Q7 Pro Max
Battery Capacity: 52V 28A 1456Wh
Motor: High-speed motor, 2 x 1600W
Tire Model: Dual-purpose tires, 10-inch diameter, 90mm width
Maximum Speed (km/h): 70 km/h
Range (km): 90-110 km
Applicable Terrain: Roads, urban off-road
Startup Method: NFC startup + password startup
Headlights: High-tech round headlights
Charging: Dual charging ports, single/dual charger included
Operating Temperature: Above -30°C
Maximum Climbing Angle: 35°
Brake Type: Hydraulic disc brakes, Brand: Point Motion
Body Material: Aluminum alloy
Body Color: Main body red and black
Maximum Load Capacity (KG): 200 KG
Ground Clearance (cm): 17 cm
Footboard Width x Length: 22.5 cm x 53 cm
Front Suspension: Hydraulic suspension
Rear Suspension: Spring suspension
Controller: 52V 28A*2
Package Includes: "Complete vehicle*1, Seat*1, Charger*2,
Hex wrench set*1, Mobile phone holder*1, 3L black EVA hanging bag"
"1. Smart large screen central control, integrating multiple vehicle function control options, gear shifting, front and rear drive switching, driving mode switching, and intelligent adjustment all in one. NFC power-on and password start, two convenient starting methods.
2. 3200W motor, with a maximum speed of 70KM/H, ideal for commuting, grocery shopping, short trips, and light urban off-roading.
3. Foldable body, easily fits into a car trunk. High-strength aluminum alloy body, durable and rust-proof.
4. 52V28A 1456Wh battery, with a range of 90-110KM, sufficient for daily use.
5. Integrated connector controller, the latest integrated connector controller allows for simple and quick replacement, solving future maintenance problems.
6. Front and rear hydraulic disc brakes for more stable and safer braking.
7. Front hydraulic suspension and rear high-strength spring suspension for a more stable and comfortable ride.
8. High-tech round headlights, acrylic side lights, rear sequential turn signals, hidden running lights, and hidden brake lights.
9. 10-inch dual-purpose tires, wear-resistant tubeless tires, 90mm wide tires, providing a larger contact surface with the ground for more stable riding.
10. Smart vehicle-to-phone connectivity, allowing real-time monitoring of vehicle status and adjustment of vehicle parameters via mobile phone. Full-featured APP with 12 language options."
Packaging Box Dimensions (L x W x H cm): 128 x 30 x 56 cm
Vehicle Dimensions (L x W x H mm): Unfolded size 116 x 22.5 x 102-120 cm
Folded Dimensions (L x W x H mm): Folded size 123 x 22.5 x 46 cm
Net Weight (KG): 33.6 KG
Gross Weight (KG): 42.3 KG
CE: Yes
FCC: Yes
ROHS: Yes
Other Certifications: Yes
Motor Brand: Jinli
Motor Model: 10-inch
Rated Voltage (V): 52V
Rated Power (W): 2*1600W
Battery Capacity (AH): 52V 28A 1456Wh
Rated Voltage (V): 52V
Charging Input Voltage (V): 58.8V
Number of Recharge Cycles: 1500 times
Charging Time (H): 4-5 hours
Battery Protection Board: Continuous 60A
Battery Warranty Period: 1 year
Charger Model: 58.8V 3A
Rated Input Voltage (V): 100-240V
Rated Output Voltage (V): 58.8V (±1V)
Rated Current (A): 3.0A (±0.2A)
Controller Type: Integrated plug-in controller
Brand: Liya
Working Current (A): 28±1A
Working Voltage (V): 52V
Undervoltage (V): 42V
Instrument Type (LCD/LED/OLED): LCD
Instrument Display Parameters: Yes
USB Output Interface: Yes
Gear Positions: Three adjustable gears
Instruction Manual: Yes
Charger: 58.8V 3A charger x2
Seat: One set of seats
Front Bag: EVA black 2L waterproof bag
Other Tools: Hex screwdriver set, chain lock, air pump, mobile phone holder
